Suitable for cleaning
- courtyards
- green areas of all kinds
- streets
- squares
Also very effective as a snowplough (using the brush without the basket)
MANUFACTURER:
--- MADE IN ITALY ---
One of the only sweepers on the market that can work in
2 different configurations:
- with collector (double)
- without collector
Normally, almost all sweepers do not have the possibility of applying the collector
It is also a POLIFUNCTIONAL machine: in fact, it can mount various types of accessories, thanks to its quick coupling and reversible handle.
ONLY THE BRUSH ACCESSORY IS INCLUDED IN THE INSERTION PRICE.
Should other accessories be desired, they are charged separately.
TECHNICAL SPECIFICATIONS:
Powerful Briggs&Stratton 850 series engine
overhead valve
this is one of the most famous engines in the world, both in the field of lawn mowers and in the gardening and agricultural sector in general. In this case, it is a state-of-the-art engine.
Briggs&Stratton engines are MADE IN USA
Recoil start with recoil starter
Gearbox: 5-speed (3+2), all usable with the mulcher attachment
3 forward gears:
1MA = 1.08 km/h
2MA = 2.51 km/h
3MA = 3.47 km/h
2 reverse gears:
1WD = 1.07 km/h
2WD = 2.07 km/h
Transmission:
gear + worm gear in oil bath + belts
The gear transmission is extremely robust and generously sized
Brush working width: 82 cm
Brush diameter: 30 cm
Brush equipped with no less than 6 rows of bristles made of special high-strength polyethylene.
The arrangement of these rows is "helical" in order to maximise the collection efficiency of the machine
Brush adjustable in height, by means of the two swivel wheels located adjacent to the brush, equipped with various levels of height adjustment
Dimensions of the double collector: 85 x 40 x 29 cm
It is equipped with 2 additional front support wheels
The machine can work both with and without the collector
Removal of the two baskets and their lower support frame is immediate and can be carried out in an instant (no tools are required for disassembly)
Close-up of one of the baskets
Brush inclination adjustable in various positions, thanks to the rotating adjustment lever.
Close-up of the rotating adjustment lever
Brush engagement/disengagement lever on the handlebars (red lever above)
Motorbike engage/disengage lever on handlebars (silver lever below)
Quick-release coupling that allows the other accessories to be fitted quite easily
Reversible and height-adjustable handlebars, both laterally and in height
Large 15 "x6.00-6 professional pneumatic drive wheels
Dark grey metallic paintwork
Weight: 85 kg
Assembly time: 40 minutes
TECHNICAL DATA
Engine B&S 850
Displacement 190 cc
Cycle Four-stroke
Feeding Green petrol
Gearbox 5 speeds of which 3 forward and 2 reverse gears
Transmission Oil-immersed gears and belts
Recoil start with recoil starter
Blade engagement/disengagement yes, lever on handlebars
Motorbike engagement/disengagement Lever on handlebars
Quick coupling for accessories yes
Brush 82 cm
Reversible and adjustable handlebars
Pneumatic drive wheels 15x6.00-6
Weight 75 kg
