Annovi & Reverberi AR 737 Cold Water Pressure Washer - 150 bar Max.

Questions & Answers (1)
ID: K502463

EAN: 8016287123617

MPN: 12361

7,8/10
After-sales assistance & Spare parts
Annovi & Reverberi AR 737 Cold Water Pressure Washer - 150 bar Max.
FREE
Gral detergent bottleGral detergent bottle
For Free: Oil & Smog Clean detergent bottleFor Free: Oil & Smog Clean detergent bottle
Mold & Moss Clean detergent bottleMold & Moss Clean detergent bottle
Free water supply connection kitFree water supply connection kit
Protection and storage tarp coverProtection and storage tarp cover
Axial pump
Pump head material
Brass
Max. flow rate per hour
480 L/h
Max. pressure
150 bar
Engine speed
2800 RPM
Engine
Induction
Operating mode
Single-phase 230 V
Pressure regulator
Yes
Wheeled
Detergent tank
Self-priming pump
Weight
32 Kg
Manufacturing country
Italy
Product Features
Model:
AR 737
Wheeled:
Type:
Wheeled
Operating mode:
Single-phase 230 V
Operation mode:
Cold water
Detergent delivery:
Low-pressure
Manufacturing country:
Italy
Motor data
Motor type:
Electric single-phase
Engine:
Induction
Motor speed:
2800 RPM
Max. power absorption:
2.7 Kw
Cooling:
With air
Manufacturing country:
Italy
Pump data
Pump brand:
Annovi & Reverberi
Model:
HPZ
Pump type:
3 axial cylinders
Axial pump:
Self-priming pump:
No. of pump speeds:
1
Pistons material:
Steel
Pump head material:
Brass
Brass pump head:
Engine speed:
2800 RPM
Max flow rate per minute:
8 L/min
Max. flow rate per hour:
480 L/h
Operating pressure:
130 bar
Max. pressure:
150 bar
Pressure regulator:
Yes
Pressure regulator:
Manufacturing country:
Italy
Equipment
Integrated detergent tank:
Yes
Detergent tank:
Detergent dispenser:
Yes
Type of attachment:
M22 - Screw
Hose holder:
Yes
Total Stop:
Yes
Rear wheels size:
170 mm
Tool holder:
Yes
Power cable holder:
Yes
Free gifts/extra features
Spray gun:
Yes
Heavy-duty spray gun:
Yes
Lance with adjustable nozzle:
Yes
Heavy-duty lance:
Yes
Hose length:
10 m
Instructions manual:
Yes
Dimensions and logistics
Product dimensions in cm (L x W x H):
39 x 38 x 90 cm
Net weight:
32 Kg
Packaging:
On pallet
Original packaging/s dimensions in cm (L x W x H):
80 x 40 x 58 cm
Gross weight (packaging included) :
35 Kg
Assembly time:
5 minutes
Prompt Delivery
1 item in stock
Free Shipping
Estimated delivery: 24/09/2024 - 26/09/2024
€ 583,77
VAT Included

You're viewing:
Customers also viewed:
Description

AR Blue Clean AR 737 Pressure Washer

Blue Clean AR 737 cold water pressure washer on trolley with pressure gauge and pressure regulator is part of 7 Series by Annovi Reverberi.

Entirely Made in Italy, guaranteeing reliability and high-quality materials and structure.

Comfortable and user-friendly, it is equipped with 17 cm diameter rubber wheels and a large non-slip handle. It weighs 32 Kg.

AR 737 is not bulky thanks to the vertical configuration and the possibility to be stored in a horizontal position. What is more, the number of compartments and hooks available on the frame allow to store all the standard-supplied accessories.

Good performance: ideal for cleaning garden furniture, tools, bikes, patios and additional applications.

Reliable products

Unlike many “single-use” items available on the market at very low price, Annovi Reverberi pressure washers come with:

  • technical support availability
  • spare parts availability
  • long-lasting product
  • high performance

Pump and Motor

Pressure: 150 bar max.

Flow rate: 8 L/min (480 L/h)

AR 737 pressure washer HPZ pump consists of 3-axial pistons driven by the swashplate and brass head.

  • Hardened stainless steel pistons
  • Automatic bypass valve.
  • Pressure regulator
  • Built-in pressure gauge
  • Remote total stop system of the pressure washer.
  • Single-phase electric motor with thermal protection.

The induction single-phase electric motor can run continuously for hours. The electric motor ensures high reliability as it does not consist of components subject to wear such as graphite brushes. The induction motor is also able to withstand the peaks and overload phases, typical of the start/stop phases of pressure washers.

Pressure is fundamental for pressure washers. Flow rate is even more important: affordable machines may often feature high-pressure but very short flow rate, resulting in inefficient products. The minimum flow rate must be at least 350 L/h.

Main Features

User-friendly start controls

“TSS" (Total Stop System)
When you release the water delivery button, the machine automatically shuts down, starting again when you continue working. Main advantages:

  • it prevents overheating
  • makes the pump more durable
  • reduces consumption

Easy access to the water filter and 5 m power cable.

  • 2 L built-in detergent tank with direct suction and adjustment knob
  • 10 m high-pressure wire armoured hose
  • The spray gun and the adjustable head are placed on the rear part of the machine
  • Carrying handle
  • Heavy-duty threaded hose fitting for easy connection to the lance and focus on the handle
  • Focus on the safety device.
  • 17 cm diameter rubber wheels
  • Optional horizontal storage

Assembly and Equipment

Free items included

  • Lance with adjustable nozzle
  • 10 m high-pressure hose
  • High-pressure gun
  • Water inlet hose adapter with filter
  • 5 m power cable
  • Accessory compartment and rear hose holder
Free items & Standard equipment

Complimentary

WATER CONNECTION KIT for pressure washer

The kit includes:

  • Ø 15 mm yellow hose, 15 m long
  • Male quick connector for tap connection (size of the standard thread: 3/4“)
  • Standard female quick connector (to insert the hose into the male quick connector for tap connection)
  • Female quick connector with WATERSTOP (to be applied to the end of the hose for connection to the high-pressure cleaner). Waterstop system: when the pressure washer, or another device is disconnected, the water flow stops automatically; when the pressure washer is re-connected, the water starts to flow again. This allows to avoid using the tap every time you disconnect the female connector from the pressure washer and every time you change the accessories.

  • Adjustable plastic lance with male quick connector.

    It is possible to connect it to the hose to use it for any job when you are not using the pressure washer. Also suitable for irrigation. It is equipped with adjustable nozzle (direct or cone).

    Also useful to rinse a surface before spreading the detergent to subsequently wash it with a pressure washer.

Fittings and hose connection diagram of this accessory on request (water connection kit)

COMPLIMENTARY: large protection and storage cover

Essential for protecting your machine when stored.

This cloth is quick and easy to apply; in a few seconds, your machine will be protected against dust and humidity.

It is equipped with an elastic band on the lower edge to perfectly fit the machine.

It is easy to fold and store in its box without taking up space!

(The pictures are for illustrative purposes only)

FOR FREE: AgriEuro Detergents Kit for Outdoor Cleaning - 3 Bottles 1 L

This AgriEuro Outdoor Detergents set includes three different 1 L bottles with different features that are essential for the cleaning of outdoor areas.

The set includes:

  • Gral: Gentle, highly effective antistatic cleaner for removing streaks and greasy dirt deposits from various types of surfaces: glass, ceramics, metal, lacquered wood, leather, plastic, etc.
  • Oil & Smog Clean: This alkaline detergent was designed for degreasing equipment, machinery, concrete and tiles effectively.
  • Recommended for removing smog from the front of houses, outdoor staircases and sidewalks.
  • Mold & Moss Clean: This chlorine acid detergent was designed to clean and sanitise at the same time. This product is essential when it comes to removing mold and moss from dark areas and environments where humidity is high. Particularly suitable for removing bad odours. Its high sanitising efficiency eliminates bacteria which cause unpleasant odour through fermentation.

Free Items Included

The pressure washer is shipped in its original packaging

Multilingual instructions

  • High-pressure gun with adjustable nozzle.
  • 10 m high-pressure hose
  • Hydraulic connection Kit
